Product Detail

Compact and lightweight design
Battery protection system automatically shuts off power when the battery level is low
LED light illuminates the work site

CXT Battery
Brushless Motor
No load speed 0 – 680 min⁻¹
Impacts per Minute (IPM) 0 – 4800 min⁻¹
Impact Energy 1,1 J
Max. Drilling Diameter in Wood 13 mm
Max. Drilling Diameter in Concrete 16 mm
Max. Drilling Diameter in Steel 10 mm
Sound Power Level (LWA) 98 dB(A)
Sound Pressure Level (LpA) 87 dB(A)
Noise Uncertainty (K Factor) 3 dB(A)
Tool weight with battery 1,8 – 2,4 kg
Product Dimensions (L x W x H): 250 x 74 x 187 mm

Nominal Battery Voltage 12 V
Battery Chemistry (Ni-Cd / Ni-MH / Li-ion) Li-ion
Optimum Drilling Diameter Range in Concrete 5 – 8 mm
Adapted for SDS-PLUS bits
Electronic brake
Product net weight 1,6 kg
Vibration Level, Hammer Drilling Into Concrete 9,3 m/s²
Vibration Uncertainty (K Factor), Hammer Drilling Into Concrete 1,5 m/s²
